Guard Rail 750mm Post with Baseplate

Delivery in 3 - 5 days. MAX 5 day delivery guarantee! Metro BNE, SYD, MEL.

ASNZ 2890.1:2004 compliant for car parks.

60 day returns. No re-stocking fees.

100% money back guarantee. Not satisfied? Full refund, no questions asked.

$150 inc GST minimum order

Buy now!

$97.00 inc GST

Notify me when back in stock

750mm Galvanised Guard Rail Post with Baseplate – Surface Mount, AS 4680 & VicRoads Compliant

Designed for surface mounting on concrete floors, this 750mm Guard Rail Post with Baseplate is the most common and trusted solution for W-beam barrier systems in warehouses, car parks, and industrial safety zones. It delivers proven strength, long-term durability, and regulatory compliance.

Manufactured from hot-dip galvanised steel and compliant with AS 4680:2006, the post features a 6mm thick “C” channel profile welded to a 300mm x 300mm x 10mm baseplate. Oversized 24mm mounting holes are engineered for 20mm true bolts or chemset studs, providing superior hold strength for high-impact areas. It can be punched to support 1, 2, or 3 rail configurations as needed.


Key Features


  • Material: Hot-dip galvanised steel
  • Finish: Galvanised – corrosion-resistant, maintenance-free
  • Height: 750mm
  • Mounting Type: Surface mount with bolt-down baseplate
  • Post Profile: 6mm “C” channel, 178mm wide with 76mm returns
  • Baseplate Size: 300mm x 300mm x 10mm thick
  • Baseplate Holes: 24mm diameter – suits 20mm bolts or chemset studs
  • Rail Compatibility: Can be punched for 1, 2, or 3 rail configurations
  • Weight: 18kg
  • Compliance: AS 4680:2006 and VicRoads 750mm height standard


Why Choose the 750mm Guard Rail Post with Baseplate?


  • Compact, compliant post for low-profile barrier setups
  • Fully galvanised for long-lasting outdoor or indoor use
  • Large baseplate with oversized bolt holes ensures secure anchoring
  • Flexible punching options for different rail layouts
  • Quick bolt-down install for concrete surfaces


Applications


  • Car parks and pedestrian safety zones
  • Factories, warehouses, and internal traffic control
  • Public infrastructure and council safety projects
  • Loading docks and access points
  • Guardrail anchoring for containment systems


Frequently Asked Questions


Is this post compliant with local regulations?
Yes, it complies with AS 4680:2006 and meets VicRoads requirements for 750mm height installations.


Can this post support multiple rails?
Yes, it can be punched to suit 1, 2, or 3 W-beam guard rails depending on your requirements.


What fixings should I use?
The 24mm holes are designed for true 20mm bolts or chemset studs. Contact us if you need recommendations.


Is custom punching available?
Yes, contact us with your configuration, and we can tailor it to your specific layout.



Need a compliant, heavy-duty post for low-height guardrails? Choose the 750mm Galvanised Guard Rail Post with Baseplate – strong, compliant, and built for Australian worksites. Buy now!

Who we've worked with

Description

750mm Galvanised Guard Rail Post with Baseplate – Surface Mount, AS 4680 & VicRoads Compliant

Designed for surface mounting on concrete floors, this 750mm Guard Rail Post with Baseplate is the most common and trusted solution for W-beam barrier systems in warehouses, car parks, and industrial safety zones. It delivers proven strength, long-term durability, and regulatory compliance.

Manufactured from hot-dip galvanised steel and compliant with AS 4680:2006, the post features a 6mm thick “C” channel profile welded to a 300mm x 300mm x 10mm baseplate. Oversized 24mm mounting holes are engineered for 20mm true bolts or chemset studs, providing superior hold strength for high-impact areas. It can be punched to support 1, 2, or 3 rail configurations as needed.


Key Features


  • Material: Hot-dip galvanised steel
  • Finish: Galvanised – corrosion-resistant, maintenance-free
  • Height: 750mm
  • Mounting Type: Surface mount with bolt-down baseplate
  • Post Profile: 6mm “C” channel, 178mm wide with 76mm returns
  • Baseplate Size: 300mm x 300mm x 10mm thick
  • Baseplate Holes: 24mm diameter – suits 20mm bolts or chemset studs
  • Rail Compatibility: Can be punched for 1, 2, or 3 rail configurations
  • Weight: 18kg
  • Compliance: AS 4680:2006 and VicRoads 750mm height standard


Why Choose the 750mm Guard Rail Post with Baseplate?


  • Compact, compliant post for low-profile barrier setups
  • Fully galvanised for long-lasting outdoor or indoor use
  • Large baseplate with oversized bolt holes ensures secure anchoring
  • Flexible punching options for different rail layouts
  • Quick bolt-down install for concrete surfaces


Applications


  • Car parks and pedestrian safety zones
  • Factories, warehouses, and internal traffic control
  • Public infrastructure and council safety projects
  • Loading docks and access points
  • Guardrail anchoring for containment systems


Frequently Asked Questions


Is this post compliant with local regulations?
Yes, it complies with AS 4680:2006 and meets VicRoads requirements for 750mm height installations.


Can this post support multiple rails?
Yes, it can be punched to suit 1, 2, or 3 W-beam guard rails depending on your requirements.


What fixings should I use?
The 24mm holes are designed for true 20mm bolts or chemset studs. Contact us if you need recommendations.


Is custom punching available?
Yes, contact us with your configuration, and we can tailor it to your specific layout.



Need a compliant, heavy-duty post for low-height guardrails? Choose the 750mm Galvanised Guard Rail Post with Baseplate – strong, compliant, and built for Australian worksites. Buy now!
